The Internet

Ever wondered how beautifully The Internet works? It's the largest thing humans have ever built (in recorded history), yet it always works perfectly and without ever breaking!

Sure, you hear of systems getting hacked and what not, but that's because of faulty and insecure software somebody wrote that runs on the internet, not the internet system itself.

It cannot break because the internet isn't a central thing. Rather, it consists of billions and billions of connected individual nodes, somewhere on the planet. Thus, if any number of them break, it is no big deal. The whole thing is still connected and can connect anybody with everyone else on it.

How the Internet Works

You may already have some ideas how the internet basically works. Take a moment to watch this well-done short video from the World Science Festival to be sure we're covered:

TCP Ensures Reliable Delivery

As you saw in the video above, the IP or Internet Protocol sets up a nice way to deliver packets between two nodes on the internet.

But delivery is by no means guaranteed by IP! Packets can get too much delayed, dropped, or lost. Connections may drop, servers may crash, and so on.

TCP or Transmission Control Protocol sits on top of IP, using it with the goal of ensuring delivery. It keeps track of packets sent, waits to receive back acknowledgment, or ACK from the destination, and makes sure the packets are received in the right order, before sending out new packets. When packets are not received, TCP resends them.

Note that we still cannot really say TCP "guarantees" delivery, because, at least theoretically, if all nodes on the internet are down nothing can get across! But still, we can definitely say it "tries hard" to ensure all packages are delivered properly to the right destination.

TCP When Everything Is Smooth

Here is a nice animation showing TCP in action when all packets are getting nicely delivered, in time and in order. Try to infer how the protocol works:

Notice that TCP isn't sending all packets at once. (If every node was sending all its packets at once, then the internet would quickly come to a grinding halt from so much congestion!. Only packets within a Sliding Window are on flight, at a given moment.

Q. How is the Sender behaving?

• The sender is only sending packets in the current sliding window.
• It does not move the sliding window until the first packet sent in the sliding window has had its ACK received back from the receiver.

Q. How is the Receiver behaving?

• For each packet received, the receiver sends the ACK for the last packet received in the proper order.
• It moves the sliding window by one position when the first packet in the window has been received, in the proper order.

TCP When Packets Are Dropped

Here is an animation showing TCP saving the day when some packets (or their ACKs) are getting dropped. Try to infer how the protocol is working:

Q. What happened when packet B got dropped?

• The receiver's ACK window only moved passed the last packet successfully delivered (A) which was ordered right before that dropped packet.
• Once C and D were received by the receiver, it rejected them because the packet before them (B) hadn't yet been received. Thus for them also it sent an ACK for A, indicating it needs to receive packets from B on.

No worries if there is too much going on here to follow! I just wanted you to get a sense of how these protocols work...
